2002 Saab 9-3
midsize luxury car / 4-door sedan
Moderate overlap front: original test
Tested vehicle: 1999 Saab 9-3 4-door
Rating applies to 1999-2002 models built after December 1998
The Saab 9-3 was restyled and renamed for the 1999 model year (it used to be called the Saab 900). All 9-3 models manufactured after December 1998 include structural changes to improve occupant protection in frontal crashes (note: information about when a specific vehicle was manufactured is on the certification label typically affixed to the car on or near the driver door).
The Insurance Institute for Highway Safety has evaluated the crashworthiness of a 9-3 with the structural changes in a 40 mph frontal offset crash test into a deformable barrier.
| Evaluation criteria | Rating |
|---|---|
| Overall evaluation | |
| Structure and safety cage | |
| Driver injury measures | |
| Head/neck | |
| Chest | |
| Leg/foot, left | |
| Leg/foot, right | |
| Driver restraints and dummy kinematics Dummy movement wasn't well controlled. During rebound, the dummy moved toward the driver door, and its head went part of the way out the open window and hit the B-pillar. There was too much upward movement of the steering wheel. |
|
Technical measurements for this test
Measures of occupant compartment intrusion on driver side
| Evaluation criteria | Measurement |
|---|---|
| Test ID | CF99004 |
| Footwell intrusion | |
| Footrest (cm) | 20 |
| Left (cm) | 24 |
| Center (cm) | 26 |
| Right (cm) | 21 |
| Brake pedal (cm) | 15 |
| Instrument panel rearward movement | |
| Left (cm) | 8 |
| Right (cm) | 7 |
| Steering column movement | |
| Upward (cm) | 14 |
| Rearward (cm) | 6 |
| A-pillar rearward movement (cm) | 11 |
Driver injury measures
| Evaluation criteria | Measurement |
|---|---|
| Test ID | CF99004 |
| Head | |
| HIC-15 | 334 |
| Peak gs at hard contact | 92 |
| Neck | |
| Tension (kN) | 1.4 |
| Extension bending moment (Nm) | 26 |
| Maximum Nij | 0.31 |
| Chest maximum compression (mm) | 29 |
| Legs | |
| Femur force - left (kN) | 3.0 |
| Femur force - right (kN) | 2.6 |
| Knee displacement - left (mm) | 7 |
| Knee displacement - right (mm) | 4 |
| Maximum tibia index - left | 0.44 |
| Maximum tibia index - right | 0.84 |
| Tibia axial force - left (kN) | 1.1 |
| Tibia axial force - right (kN) | 4.4 |
| Foot acceleration (g) | |
| Left | 78 |
| Right | 82 |
