Small overlap front: driver-side
Rating applies to 2020-23 models
Tested vehicle: 2020 Ford Escape SE 4-door 4wd
The Ford Escape was redesigned for the 2020 model year, and the Lincoln Corsair was introduced in the same model year. The Corsair replaces the Lincoln MKC.
Overall evaluation | |
---|---|
Structure and safety cage | |
Driver injury measures | |
Head/neck | |
Chest | |
Hip/thigh | |
Lower leg/foot | |
Driver restraints and dummy kinematics |

Action shot taken during the driver-side small overlap frontal crash test.

The dummy's position in relation to the door frame, steering wheel, and instrument panel after the crash test indicates that the driver's survival space was maintained very well.

The frontal and side curtain airbags worked well together to keep the head from coming close to any stiff structure or outside objects that could cause injury.

The driver's space was maintained well, and risk of injuries to the dummy's legs and feet was low.
Measures of occupant compartment intrusion on driver side
Test ID | CEN1910 |
---|---|
Lower occupant compartment | |
Lower hinge pillar max (cm) | 2 |
Footrest (cm) | 2 |
Left toepan (cm) | 1 |
Brake pedal (cm) | 1 |
Parking brake (cm) | |
Rocker panel lateral average (cm) | 1 |
Upper occupant compartment | |
Steering column | 0 |
Upper hinge pillar max (cm) | 1 |
Upper dash (cm) | 1 |
Lower instrument panel (cm) | 1 |
Driver injury measures
Test ID | CEN1910 |
---|---|
Head | |
HIC-15 | 80 |
Peak gs at hard contact | no contact |
Neck | |
Tension (kN) | 1.0 |
Extension bending moment (Nm) | 15 |
Maximum Nij | 0.23 |
Chest maximum compression (mm) | 24 |
Femur (kN) | |
Left | 0.1 |
Right | 0.0 |
Knee displacement (mm) | |
Left | 1 |
Right | 2 |
Knee-thigh-hip injury risk (%) | |
Left | 0 |
Right | 0 |
Maximum tibia index | |
Left | 0.42 |
Right | 0.33 |
Tibia axial force (kN) | |
Left | 1.1 |
Right | 0.1 |
Foot acceleration (g) | |
Left | 43 |
Right | 19 |
Small overlap front: passenger-side
Rating applies to 2020-23 models
Tested vehicle: 2020 Ford Escape SE 4-door 4wd
The Ford Escape was redesigned for the 2020 model year, and the Lincoln Corsair was introduced in the same model year. The Corsair replaces the Lincoln MKC. Passenger-side small overlap frontal ratings are assigned by the Institute based on a test conducted by Ford as part of frontal crash test verification.
Overall evaluation | |
---|---|
Structure and safety cage | |
Passenger injury measures | |
Head/neck | |
Chest | |
Hip/thigh | |
Lower leg/foot | |
Passenger restraints and dummy kinematics | |
Driver injury measures | |
Head/neck | |
Chest | |
Hip/thigh | |
Lower leg/foot | |
Driver restraints and dummy kinematics |
Measures of occupant compartment intrusion on passenger side
Test ID | VTP1931 |
---|---|
Lower occupant compartment | |
Lower hinge pillar max (cm) | 7 |
Footrest (cm) | 4 |
Right toepan (cm) | 8 |
Center toepan (cm) | 1 |
Rocker panel lateral average (cm) | 0 |
Upper occupant compartment | |
Center dash (cm) | 6 |
Upper hinge pillar max (cm) | 9 |
Upper dash (cm) | 9 |
Right lower dash (cm) | 8 |
Passenger injury measures
Test ID | VTP1931 |
---|---|
Head | |
HIC-15 | 78 |
Peak gs at hard contact | no contact |
Neck | |
Tension (kN) | 0.8 |
Extension bending moment (Nm) | 11 |
Maximum Nij | 0.20 |
Chest maximum compression (mm) | 21 |
Femur (kN) | |
Left | 1.0 |
Right | 4.8 |
Knee displacement (mm) | |
Left | 2 |
Right | 4 |
Knee-thigh-hip injury risk (%) | |
Left | 0 |
Right | 3 |
Maximum tibia index | |
Left | 0.29 |
Right | 0.39 |
Tibia axial force (kN) | |
Left | 0.9 |
Right | 0.7 |
Foot acceleration (g) | |
Left | 75 |
Right | 52 |
Driver injury measures
Test ID | VTP1931 |
---|---|
Head | |
HIC-15 | 72 |
Peak gs at hard contact | no contact |
Neck | |
Tension (kN) | 0.8 |
Extension bending moment (Nm) | 7 |
Maximum Nij | 0.16 |
Chest maximum compression (mm) | 25 |
Femur (kN) | |
Left | 0.0 |
Right | 0.1 |
Knee displacement (mm) | |
Left | 1 |
Right | 1 |
Knee-thigh-hip injury risk (%) | |
Left | 0 |
Right | 0 |
Maximum tibia index | |
Left | 0.44 |
Right | 0.21 |
Tibia axial force (kN) | |
Left | 0.2 |
Right | 0.2 |
Foot acceleration (g) | |
Left | 19 |
Right | 36 |
How the passenger-side small overlap front test is conducted
Moderate overlap front: original test
Rating applies to 2020-23 models
Tested vehicle: 2020 Ford Escape SE 4-door 4wd
The Ford Escape was redesigned for the 2020 model year, and the Lincoln Corsair was introduced in the same model year. The Corsair replaces the Lincoln MKC. Moderate overlap frontal ratings are assigned by the Institute based on a test conducted by Ford as part of frontal crash test verification.
Overall evaluation | |
---|---|
Structure and safety cage | |
Driver injury measures | |
Head/neck | |
Chest | |
Leg/foot, left | |
Leg/foot, right | |
Driver restraints and dummy kinematics |
Measures of occupant compartment intrusion on driver side
Test ID | VTF1921 |
---|---|
Footwell intrusion | |
Footrest (cm) | 3 |
Left (cm) | 6 |
Center (cm) | 5 |
Right (cm) | 4 |
Brake pedal (cm) | 7 |
Instrument panel rearward movement | |
Left (cm) | -1 |
Right (cm) | 0 |
Steering column movement | |
Upward (cm) | -1 |
Rearward (cm) | -1 |
A-pillar rearward movement (cm) | 0 |
Driver injury measures
Test ID | VTF1921 |
---|---|
Head | |
HIC-15 | 276 |
Peak gs at hard contact | no contact |
Neck | |
Tension (kN) | 0.8 |
Extension bending moment (Nm) | 8 |
Maximum Nij | 0.23 |
Chest maximum compression (mm) | 25 |
Legs | |
Femur force - left (kN) | 0.4 |
Femur force - right (kN) | 0.5 |
Knee displacement - left (mm) | 1 |
Knee displacement - right (mm) | 1 |
Maximum tibia index - left | 0.25 |
Maximum tibia index - right | 0.34 |
Tibia axial force - left (kN) | 1.9 |
Tibia axial force - right (kN) | 2.5 |
Foot acceleration (g) | |
Left | 57 |
Right | 67 |
Moderate overlap front: updated test
Rating applies to 2022-23 models built after May 2022
Tested vehicle: 2022 Ford Escape SE 4-door 4wd
The Ford Escape was redesigned for the 2020 model year. Beginning with 2022 Escape models built after May 2022, improvements were made to the rear seatbelt to improve rear occupant protection in moderate overlap front crashes (Information about when a specific vehicle was manufactured is on the certification label typically affixed to the driver door or adjacent B-pillar).
Overall evaluation | |
---|---|
Structure and safety cage | |
Driver injury measures | |
Head/neck | |
Chest | |
Thigh/hip | |
Leg/foot | |
Driver restraints and dummy kinematics | |
Rear passenger injury measures | |
Head/neck | |
Chest | |
Thigh | |
Rear passenger restraints and dummy kinematics |

View of the vehicle after the crash showing the airbags and damage to the occupant compartment.

The rear passenger dummy's head approached the front seatback, which increases the risk of head injuries.

Rear passenger dummy injury values indicate a low risk of injury to the head or neck and chest.

The rear passenger dummy's lap belt remained in the ideal position on the pelvis.
Measures of occupant compartment intrusion on driver side
Test ID | CEF2226 |
---|---|
Footwell intrusion | |
Footrest (cm) | 3 |
Left (cm) | 4 |
Center (cm) | 6 |
Right (cm) | 4 |
Brake pedal (cm) | 3 |
Instrument panel rearward movement | |
Left (cm) | 0 |
Right (cm) | 0 |
Steering column movement | |
Upward (cm) | -1 |
Rearward (cm) | -3 |
A-pillar rearward movement (cm) | 0 |
Driver injury measures
Test ID | CEF2226 |
---|---|
Head | |
HIC-15 | 122 |
Peak gs at hard contact | no contact |
Neck | |
Tension (kN) | 0.8 |
Extension bending moment (Nm) | 9 |
Maximum Nij | 0.23 |
Chest maximum compression (mm) | 27 |
Femur (kN) | |
Left | 0.3 |
Right | 0.4 |
Knee displacement (mm) | |
Left | 1 |
Right | 1 |
Knee-thigh-hip injury risk (%) | |
Left | 0 |
Right | 0 |
Maximum tibia index | |
Left | 0.25 |
Right | 0.34 |
Tibia axial force (kN) | |
Left | 1.7 |
Right | 1.3 |
Foot acceleration (g) | |
Left | 47 |
Right | 91 |
Rear passenger injury measures
Test ID | CEF2226 |
---|---|
Head | |
HIC-15 for head contact during forward excursion |
no contact
|
Peak gs at hard contact | no contact |
Neck | |
Tension (kN) | 1.8 |
Compression (kN) | 0.3 |
Maximum Nij for head contact during forward excursion |
no contact
|
Chest | |
Chest maximum compression (mm) | 21 |
Shoulder belt tension (kN) | 4.5 |
Maximum shoulder belt position (mm) | 87 |
Thigh (kN) | |
Left femur compression | 0.1 |
Right femur compression | 0.1 |
Side: original test
Rating applies to 2020-23 models
Tested vehicle: 2020 Ford Escape SE 4-door 4wd
The Ford Escape was redesigned for the 2020 model year, and the Lincoln Corsair was introduced in the same model year. The Corsair replaces the Lincoln MKC. Side ratings are assigned by the Institute based on a test conducted by Ford as part of side crash test verification.
Overall evaluation | |
---|---|
Structure and safety cage | |
Driver injury measures | |
Head/neck | |
Torso | |
Pelvis/leg | |
Driver head protection | |
Rear passenger injury measures | |
Head/neck | |
Torso | |
Pelvis/leg | |
Rear passenger head protection |
Measures of occupant compartment intrusion on driver side
Test ID | VTS1922 | |
---|---|---|
B-pillar to longitudinal centerline of driver's seat (cm) | -22.5 | |
Negative numbers indicate the amount by which the crush stopped short of the seat centerline. |
Driver injury measures
Test ID | VTS1922 |
---|---|
Head HIC-15 | 193 |
Neck | |
Tension (kN) | 1.8 |
Compression (kN) | 0.5 |
Shoulder | |
Lateral deflection (mm) | 45 |
Lateral force (kN) | 1.7 |
Torso | |
Maximum deflection (mm) | 38 |
Average deflection (mm) | 34 |
Maximum deflection rate (m/s) | 4.06 |
Maximum viscous criterion (m/s) | 0.78 |
Pelvis | |
Iliac force (kN) | 1.0 |
Acetabulum force (kN) | 1.6 |
Combined force (kN) | 2.6 |
Left femur | |
L-M force (kN) | 0.2 |
L-M moment (Nm) | 71 |
A-P moment (Nm) | 26 |
Passenger injury measures
Test ID | VTS1922 |
---|---|
Head HIC-15 | 108 |
Neck | |
Tension (kN) | 0.4 |
Compression (kN) | 0.1 |
Shoulder | |
Lateral deflection (mm) | 37 |
Lateral force (kN) | 1.2 |
Torso | |
Maximum deflection (mm) | 32 |
Average deflection (mm) | 27 |
Maximum deflection rate (m/s) | 1.89 |
Maximum viscous criterion (m/s) | 0.27 |
Pelvis | |
Iliac force (kN) | 0.5 |
Acetabulum force (kN) | 2.4 |
Combined force (kN) | 2.4 |
Left femur | |
L-M force (kN) | 0.1 |
L-M moment (Nm) | 80 |
A-P moment (Nm) | 17 |
Side: updated test
Rating applies to 2020-23 models
Tested vehicle: 2021 Ford Escape S 4-door 4wd
The Ford Escape was redesigned for the 2020 model year, and the Lincoln Corsair was introduced in the same model year. The Corsair replaces the Lincoln MKC.
Overall evaluation | |
---|---|
Structure and safety cage | |
Driver injury measures | |
Head/neck | |
Torso | |
Pelvis | |
Driver head protection The dummy's head moved downward past the side curtain airbag and struck the window sill of the driver door hard, while the head was in proximity to the intruding barrier. Although the barrier did not hit the dummy's head in this test, this near miss indicates that only slightly different crash circumstances could produce a direct hit to a person's head. The head protection is inadequate. |
|
Rear passenger injury measures | |
Head/neck | |
Torso | |
Pelvis | |
Rear passenger head protection |

View of the vehicle just after the crash test.

View of the vehicle after the crash with doors removed, showing the side airbags and damage to the occupant compartment.

Smeared greasepaint shows that the driver dummy's head moved downward, past the side curtain airbag, and contacted the window sill (inset).

Smeared greasepaint shows where the rear passenger dummy’s head was protected by the side airbags.
Measures of occupant compartment intrusion on driver side
Test ID | CES2105 | |
---|---|---|
B-pillar to longitudinal centerline of driver's seat (cm) | -17.0 | |
Negative numbers indicate the amount by which the crush stopped short of the seat centerline. |
Driver injury measures
Test ID | CES2105 |
---|---|
Head | |
HIC-15 | 391 |
Peak gs at hard contact | 93 |
Neck | |
Tension (kN) | 1.7 |
Compression (kN) | 0.1 |
Shoulder | |
Lateral deflection (mm) | 28 |
Lateral force (kN) | 1.0 |
Torso | |
Maximum deflection (mm) | 45 |
Average deflection (mm) | 39 |
Maximum deflection rate (m/s) | 3.66 |
Maximum viscous criterion (m/s) | 0.64 |
Pelvis | |
Combined force (kN) | 5.2 |
Passenger injury measures
Test ID | CES2105 |
---|---|
Head | |
HIC-15 | 168 |
Peak gs at hard contact | no contact |
Neck | |
Tension (kN) | 0.9 |
Compression (kN) | 0.2 |
Shoulder | |
Lateral deflection (mm) | 39 |
Lateral force (kN) | 1.7 |
Torso | |
Maximum deflection (mm) | 38 |
Average deflection (mm) | 35 |
Maximum deflection rate (m/s) | 2.34 |
Maximum viscous criterion (m/s) | 0.41 |
Pelvis | |
Combined force (kN) | 4.9 |
Roof strength
Rating applies to 2020-23 models
Tested vehicle: 2020 Ford Escape SE 4-door 4wd
Overall evaluation | |
---|---|
Curb weight | 3,480 lbs |
Peak force | 19,700 lbs |
Strength-to-weight ratio | 5.66 |
Head restraints & seats
Seat type: Power cloth seat
Overall evaluation | |
---|---|
Dynamic rating | |
Seat/head restraint geometry |
Seat type | Power cloth seat |
---|---|
Geometry | |
Backset (mm) | 8 |
Distance below top of head (mm) | 6 |
Seat design parameters | |
Pass/fail | Pass |
Max T1 acceleration (g) | 10.0 |
Head contact time (ms) | 53 |
Force rating | 1 |
Neck forces | |
Max neck shear force (N) | 0 |
Max neck tension (N) | 294 |
How the head restraint & seat test is conducted
Currently, IIHS tests apply only to front seats.
Child seat anchors
Applies to 2020-23 models
Overall evaluation |
+
extra LATCH positions
|
Vehicle trim | SE |
Seat type | cloth |
This vehicle has 2 rear seating positions with complete child seat attachment (LATCH) hardware.
It has 1 additional seating position with a tether anchor and the ability to borrow lower anchors from the other seating positions.
Note: When anchors are borrowed, they aren't available to use in their designated positions.
Overall evaluation |
+
extra LATCH positions
|
Vehicle trim | SE |
Seat type | cloth |
G | Good |
A | Acceptable |
M | Marginal |
P | Poor |
|
Seating positions that rely on borrowed lower anchors or have only a tether anchor available are not rated. |
thether anchor symbol
|
Tether anchor |
lower anchor symbol
|
Lower anchors |
Lower anchor(s) can be borrowed from adjacent positions(s) | |
|
No hardware available |
Details by seating position
1 | |
---|---|
Tether anchor | |
easy-to-find location | |
no other hardware could be confused for anchor | |
Lower anchors | |
not too deep in seat | |
not too much force needed to attach | |
easy to maneuver around anchors | |
2 | |
Tether anchor | |
easy-to-find location | |
no other hardware could be confused for anchor | |
Lower anchors | |
Can be borrowed from 1 and 3 | |
3 | |
Tether anchor | |
easy-to-find location | |
no other hardware could be confused for anchor | |
Lower anchors | |
not too deep in seat | |
not too much force needed to attach | |
easy to maneuver around anchors |
Seat position 21
Lower anchor A | |
---|---|
Open access rated | Yes |
Depth | Visible |
Force (lbs) | 0 |
Clearance angle (degrees) | 74 |
Lower anchor B | |
Open access rated | Yes |
Depth | Visible |
Force (lbs) | 0 |
Clearance angle (degrees) | 74 |
Tether anchor | |
Location | Middle seatback |
Confusing hardware present | Yes |
Has contrasting label within 3 inches of tether anchor |
Yes |
Seat position 22
Lower anchor A | |
---|---|
Lower latch is shared for this seat position | |
Lower anchor B | |
Lower latch is shared for this seat position | |
Tether anchor | |
Location | Middle seatback |
Confusing hardware present | Yes |
Has contrasting label within 3 inches of tether anchor |
Yes |
Seat position 23
Lower anchor A | |
---|---|
Open access rated | Yes |
Depth | Visible |
Force (lbs) | 1 |
Clearance angle (degrees) | 63 |
Lower anchor B | |
Open access rated | Yes |
Depth | Visible |
Force (lbs) | 1 |
Clearance angle (degrees) | 75 |
Tether anchor | |
Location | Middle seatback |
Confusing hardware present | Yes |
Has contrasting label within 3 inches of tether anchor |
Yes |
