Small overlap front: driver-side
Rating applies to 2019-24 models
Tested vehicle: 2016 Lincoln MKX Select 4-door 4wd
The Lincoln MKX was redesigned for the 2016 model year. Beginning with the 2019 model year, the Lincoln MKX was restyled and renamed the Lincoln Nautilus. Also beginning with the 2019 model year, the Ford Edge was modified using the same body and bumper structure as in the Lincoln MKX since 2016. Therefore, all ratings on this page apply to the Ford Edge beginning with 2019 models, the Lincoln Nautilus, and Lincoln MKX.
Overall evaluation | |
---|---|
Structure and safety cage | |
Driver injury measures | |
Head/neck | |
Chest | |
Hip/thigh | |
Lower leg/foot | |
Driver restraints and dummy kinematics |
Action shot taken during the small overlap frontal crash test.
The dummy's position in relation to the door frame, steering wheel, and instrument panel after the crash test indicates that the driver's survival space was maintained very well.
The frontal and side curtain airbags worked well together to keep the head from coming close to any stiff structure or outside objects that could cause injury.
The driver's space was maintained well, and risk of injuries to the dummy's legs and feet was low.
Measures of occupant compartment intrusion on driver side
Test ID | CEN1611 |
---|---|
Lower occupant compartment | |
Lower hinge pillar max (cm) | 9 |
Footrest (cm) | 4 |
Left toepan (cm) | 4 |
Brake pedal (cm) | 5 |
Parking brake (cm) | |
Rocker panel lateral average (cm) | 4 |
Upper occupant compartment | |
Steering column | 2 |
Upper hinge pillar max (cm) | 8 |
Upper dash (cm) | 5 |
Lower instrument panel (cm) | 6 |
Driver injury measures
Test ID | CEN1611 |
---|---|
Head | |
HIC-15 | 69 |
Peak gs at hard contact | no contact |
Neck | |
Tension (kN) | 0.9 |
Extension bending moment (Nm) | 10 |
Maximum Nij | 0.20 |
Chest maximum compression (mm) | 26 |
Femur (kN) | |
Left | 0.8 |
Right | 0.6 |
Knee displacement (mm) | |
Left | 2 |
Right | 0 |
Knee-thigh-hip injury risk (%) | |
Left | 0 |
Right | 0 |
Maximum tibia index | |
Left | 0.40 |
Right | 0.37 |
Tibia axial force (kN) | |
Left | 1.4 |
Right | 0.8 |
Foot acceleration (g) | |
Left | 29 |
Right | 28 |
Small overlap front: passenger-side
Rating applies to 2019-24 models
Tested vehicle: 2018 Lincoln MKX Select 4-door 4wd
The Lincoln MKX was redesigned for the 2016 model year. Passenger-side small overlap frontal ratings are assigned by the Institute based on a test conducted by Ford as part of frontal crash test verification.
Beginning with the 2019 model year, the Lincoln MKX was restyled and renamed the Lincoln Nautilus. Also beginning with the 2019 model year, the Ford Edge was modified using the same body and bumper structure as in the Lincoln MKX since 2016. Therefore, all ratings on this page apply to the Ford Edge beginning with 2019 models, the Lincoln Nautilus, and Lincoln MKX.
Overall evaluation | |
---|---|
Structure and safety cage | |
Passenger injury measures | |
Head/neck | |
Chest | |
Hip/thigh | |
Lower leg/foot | |
Passenger restraints and dummy kinematics | |
Driver injury measures | |
Head/neck | |
Chest | |
Hip/thigh | |
Lower leg/foot | |
Driver restraints and dummy kinematics |
Measures of occupant compartment intrusion on passenger side
Test ID | VTP1722 |
---|---|
Lower occupant compartment | |
Lower hinge pillar max (cm) | 9 |
Footrest (cm) | 3 |
Right toepan (cm) | 4 |
Center toepan (cm) | 2 |
Rocker panel lateral average (cm) | 2 |
Upper occupant compartment | |
Center dash (cm) | 4 |
Upper hinge pillar max (cm) | 7 |
Upper dash (cm) | 5 |
Right lower dash (cm) | 7 |
Passenger injury measures
Test ID | VTP1722 |
---|---|
Head | |
HIC-15 | 110 |
Peak gs at hard contact | no contact |
Neck | |
Tension (kN) | 0.9 |
Extension bending moment (Nm) | 13 |
Maximum Nij | 0.19 |
Chest maximum compression (mm) | 25 |
Femur (kN) | |
Left | 0.1 |
Right | 0.5 |
Knee displacement (mm) | |
Left | 0 |
Right | 2 |
Knee-thigh-hip injury risk (%) | |
Left | 0 |
Right | 0 |
Maximum tibia index | |
Left | 0.36 |
Right | 0.27 |
Tibia axial force (kN) | |
Left | 0.8 |
Right | 0.8 |
Foot acceleration (g) | |
Left | 19 |
Right | 28 |
Driver injury measures
Test ID | VTP1722 |
---|---|
Head | |
HIC-15 | 32 |
Peak gs at hard contact | no contact |
Neck | |
Tension (kN) | 0.8 |
Extension bending moment (Nm) | 9 |
Maximum Nij | 0.16 |
Chest maximum compression (mm) | 21 |
Femur (kN) | |
Left | 0.5 |
Right | 0.4 |
Knee displacement (mm) | |
Left | 1 |
Right | 0 |
Knee-thigh-hip injury risk (%) | |
Left | 1 |
Right | 0 |
Maximum tibia index | |
Left | 0.31 |
Right | 0.32 |
Tibia axial force (kN) | |
Left | 0.7 |
Right | 0.9 |
Foot acceleration (g) | |
Left | 31 |
Right | 52 |
How the passenger-side small overlap front test is conducted
Moderate overlap front: original test
Rating applies to 2015-24 models
Tested vehicle: 2015 Ford Edge SEL 4-door 4wd
The Ford Edge was redesigned for the 2015 model year, and the Lincoln MKX was redesigned for the 2016 model year. Moderate overlap frontal ratings are assigned by the Institute based on a test conducted by Ford as part of frontal crash test verification.
Beginning with the 2019 model year, the Lincoln MKX was restyled and renamed the Lincoln Nautilus. All ratings on this page apply to the Edge, MKX, and Nautilus.
Overall evaluation | |
---|---|
Structure and safety cage | |
Driver injury measures | |
Head/neck | |
Chest | |
Leg/foot, left | |
Leg/foot, right | |
Driver restraints and dummy kinematics |
Measures of occupant compartment intrusion on driver side
Test ID | VTF1417 |
---|---|
Footwell intrusion | |
Footrest (cm) | 3 |
Left (cm) | 5 |
Center (cm) | 3 |
Right (cm) | 6 |
Brake pedal (cm) | 9 |
Instrument panel rearward movement | |
Left (cm) | 0 |
Right (cm) | 1 |
Steering column movement | |
Upward (cm) | 0 |
Rearward (cm) | -5 |
A-pillar rearward movement (cm) | 0 |
Driver injury measures
Test ID | VTF1417 |
---|---|
Head | |
HIC-15 | 189 |
Peak gs at hard contact | no contact |
Neck | |
Tension (kN) | 1.1 |
Extension bending moment (Nm) | 9 |
Maximum Nij | 0.25 |
Chest maximum compression (mm) | 26 |
Legs | |
Femur force - left (kN) | 0.8 |
Femur force - right (kN) | 1.2 |
Knee displacement - left (mm) | 3 |
Knee displacement - right (mm) | 1 |
Maximum tibia index - left | 0.24 |
Maximum tibia index - right | 0.36 |
Tibia axial force - left (kN) | 1.2 |
Tibia axial force - right (kN) | 2.3 |
Foot acceleration (g) | |
Left | 39 |
Right | 61 |
Side: original test
Rating applies to 2015-23 models
Tested vehicle: 2015 Ford Edge SEL 4-door 4wd
The Ford Edge was redesigned for the 2015 model year, and the Lincoln MKX was redesigned for the 2016 model year. Side ratings are assigned by the Institute based on a test conducted by Ford as part of side crash test verification.
Beginning with the 2019 model year, the Lincoln MKX was restyled and renamed the Lincoln Nautilus. All ratings on this page apply to the Edge, MKX, and Nautilus.
Overall evaluation | |
---|---|
Structure and safety cage | |
Driver injury measures | |
Head/neck | |
Torso | |
Pelvis/leg | |
Driver head protection | |
Rear passenger injury measures | |
Head/neck | |
Torso | |
Pelvis/leg | |
Rear passenger head protection |
Measures of occupant compartment intrusion on driver side
Test ID | VTS1418 |
---|---|
B-pillar to longitudinal centerline of driver's seat (cm) | -20.0 |
Negative numbers indicate the amount by which the crush stopped short of the seat centerline. |
Driver injury measures
Test ID | VTS1418 |
---|---|
Head HIC-15 | 89 |
Neck | |
Tension (kN) | 0.7 |
Compression (kN) | 0.4 |
Shoulder | |
Lateral deflection (mm) | 37 |
Lateral force (kN) | 1.5 |
Torso | |
Maximum deflection (mm) | 30 |
Average deflection (mm) | 24 |
Maximum deflection rate (m/s) | 2.74 |
Maximum viscous criterion (m/s) | 0.30 |
Pelvis | |
Iliac force (kN) | 1.0 |
Acetabulum force (kN) | 1.5 |
Combined force (kN) | 2.4 |
Left femur | |
L-M force (kN) | 0.7 |
L-M moment (Nm) | 13 |
A-P moment (Nm) | 90 |
Passenger injury measures
Test ID | VTS1418 |
---|---|
Head HIC-15 | 68 |
Neck | |
Tension (kN) | 0.2 |
Compression (kN) | 0.3 |
Shoulder | |
Lateral deflection (mm) | 35 |
Lateral force (kN) | 1.8 |
Torso | |
Maximum deflection (mm) | 28 |
Average deflection (mm) | 21 |
Maximum deflection rate (m/s) | 3.27 |
Maximum viscous criterion (m/s) | 0.32 |
Pelvis | |
Iliac force (kN) | 0.2 |
Acetabulum force (kN) | 1.8 |
Combined force (kN) | 1.8 |
Left femur | |
L-M force (kN) | 0.7 |
L-M moment (Nm) | 28 |
A-P moment (Nm) | 107 |
Roof strength
Rating applies to 2015-23 models
Tested vehicle: 2015 Ford Edge SEL 4-door 4wd
Overall evaluation | |
---|---|
Curb weight | 4,237 lbs |
Peak force | 21,652 lbs |
Strength-to-weight ratio | 5.11 |
Head restraints & seats
Seat type: Power leather seat
Overall evaluation | |
---|---|
Dynamic rating | |
Seat/head restraint geometry |
Seat type | Power leather seat |
---|---|
Geometry | |
Backset (mm) | 24 |
Distance below top of head (mm) | 34 |
Seat design parameters | |
Pass/fail | Pass |
Max T1 acceleration (g) | 12.1 |
Head contact time (ms) | 56 |
Force rating | 1 |
Neck forces | |
Max neck shear force (N) | 0 |
Max neck tension (N) | 642 |
How the head restraint & seat test is conducted
Currently, IIHS tests apply only to front seats.
Headlights
Ratings are given for 4 different headlight variations available on this vehicle.
Trim level(s)
- Titanium trim equipped with 301A package; built after March 2019
- ST trim equipped with 401A package; built after March 2019
Low-beam headlight type | LED projector |
---|---|
High-beam headlight type | LED projector |
Curve-adaptive? | Yes |
High-beam assist? | Yes |
Overall rating | |
Distance at which headlights provide at least 5 lux illumination: |
Low beams
On the straightaway, visibility was good on both sides of the road. On curves, visibility was good on the sharp left and both right curves and fair on the gradual left curve.
The low beams created some glare.
High beams
On the straightaway, visibility was fair on the right side of the road and inadequate on the left side. On curves, visibility was good in all 4 tests.
High-beam assist compensates for some limitations of this vehicle's low beams on the straightaway and on both left curves.
Trim level(s) |
|
---|---|
Low-beam headlight type | LED projector |
High-beam headlight type | LED projector |
Curve-adaptive? | Yes |
High-beam assist? | Yes |
Overall rating Applies to 2019-24 models built after March 2019 |
LOW BEAMS | Average minimum useful illumination distance (5 lux) |
Amount glare exceeded threshold |
---|---|---|
Straightaway right edge | 99.4 m | 18.9% |
Straightaway left edge | 58.0 m | 18.9% |
250m radius right curve, right edge | 77.8 m | 14.6% |
250m radius left curve, left edge | 57.6 m | None |
150m radius right curve, right edge | 71.8 m | None |
150m radius left curve, right edge | 56.8 m | 5.9% |
HIGH BEAMS | Average minimum useful illumination distance (5 lux) |
---|---|
Straightaway right edge | 134.8 m |
Straightaway left edge | 117.3 m |
250m radius right curve, right edge | 89.5 m |
250m radius left curve, left edge | 83.9 m |
150m radius right curve, right edge | 75.4 m |
150m radius left curve, left edge | 73.2 m |
Trim level(s)
- SE trim; built after March 2019
- SEL trim; built after March 2019
- Titanium trim; built after March 2019
- ST trim; built after March 2019
Low-beam headlight type | LED projector |
---|---|
High-beam headlight type | LED projector |
Curve-adaptive? | No |
High-beam assist? | Yes |
Overall rating | |
Distance at which headlights provide at least 5 lux illumination: |
Low beams
On the straightaway, visibility was good on both sides of the road. On curves, visibility was good on the gradual right and sharp left curves and fair on the gradual left and sharp right curves.
The low beams created excessive glare.
High beams
On the straightaway, visibility was inadequate on both sides of the road. On curves, visibility was fair on the gradual right and both left curves and inadequate on the sharp right curve.
High-beam assist compensates for some limitations of this vehicle's low beams on both left curves and on both right curves.
Trim level(s) |
|
---|---|
Low-beam headlight type | LED projector |
High-beam headlight type | LED projector |
Curve-adaptive? | No |
High-beam assist? | Yes |
Overall rating Applies to 2019-24 models built after March 2019 |
LOW BEAMS | Average minimum useful illumination distance (5 lux) |
Amount glare exceeded threshold |
---|---|---|
Straightaway right edge | 101.5 m | 201.8% |
Straightaway left edge | 65.6 m | 201.8% |
250m radius right curve, right edge | 68.5 m | 20.0% |
250m radius left curve, right edge | 64.7 m | 117.9% |
150m radius right curve, right edge | 52.5 m | 47.1% |
150m radius left curve, left edge | 56.3 m | 140.3% |
HIGH BEAMS | Average minimum useful illumination distance (5 lux) |
---|---|
Straightaway right edge | 113.3 m |
Straightaway left edge | 99.8 m |
250m radius right curve, right edge | 70.0 m |
250m radius left curve, left edge | 71.9 m |
150m radius right curve, right edge | 53.9 m |
150m radius left curve, left edge | 57.3 m |
Trim level(s)
- SE trim; built before April 2019
- SEL trim; built before April 2019
- Titanium trim; built before April 2019
- ST trim; built before April 2019
Low-beam headlight type | LED projector |
---|---|
High-beam headlight type | LED projector |
Curve-adaptive? | No |
High-beam assist? | Yes |
Overall rating | |
Distance at which headlights provide at least 5 lux illumination: |
Low beams
On the straightaway, visibility was good on both sides of the road. On curves, visibility was good in all 4 tests.
The low beams created excessive glare.
High beams
On the straightaway, visibility was inadequate on both sides of the road. On curves, visibility was fair in all 4 tests.
High-beam assist compensates for some limitations of this vehicle's low beams on the sharp left curve and on the sharp right curve.
Trim level(s) |
|
---|---|
Low-beam headlight type | LED projector |
High-beam headlight type | LED projector |
Curve-adaptive? | No |
High-beam assist? | Yes |
Overall rating Applies to 2019 models built before April 2019 |
LOW BEAMS | Average minimum useful illumination distance (5 lux) |
Amount glare exceeded threshold |
---|---|---|
Straightaway right edge | 111.6 m | 195.9% |
Straightaway left edge | 71.5 m | 195.9% |
250m radius right curve, right edge | 73.2 m | 142.5% |
250m radius left curve, left edge | 70.5 m | 168.4% |
150m radius right curve, right edge | 56.9 m | 223.2% |
150m radius left curve, left edge | 56.5 m | 167.8% |
HIGH BEAMS | Average minimum useful illumination distance (5 lux) |
---|---|
Straightaway right edge | 113.6 m |
Straightaway left edge | 73.7 m |
250m radius right curve, right edge | 73.7 m |
250m radius left curve, left edge | 73.2 m |
150m radius right curve, right edge | 58.2 m |
150m radius left curve, left edge | 57.6 m |
Trim level(s)
- Titanium trim equipped with 301A package; built before April 2019
- ST trim equipped with 401A package; built before April 2019
Low-beam headlight type | LED projector |
---|---|
High-beam headlight type | LED projector |
Curve-adaptive? | Yes |
High-beam assist? | Yes |
Overall rating | |
Distance at which headlights provide at least 5 lux illumination: |
Low beams
On the straightaway, visibility was good on both sides of the road. On curves, visibility was good in all 4 tests.
The low beams created excessive glare.
High beams
On the straightaway, visibility was inadequate on both sides of the road. On curves, visibility was good on the gradual right and gradual left curves and fair on the sharp left and sharp right curves.
High-beam assist compensates for some limitations of this vehicle's low beams on the sharp left curve and on the sharp right curve.
Trim level(s) |
|
---|---|
Low-beam headlight type | LED projector |
High-beam headlight type | LED projector |
Curve-adaptive? | Yes |
High-beam assist? | Yes |
Overall rating Applies to 2019 models built before April 2019 |
LOW BEAMS | Average minimum useful illumination distance (5 lux) |
Amount glare exceeded threshold |
---|---|---|
Straightaway right edge | 112.7 m | 286.2% |
Straightaway left edge | 67.8 m | 286.2% |
250m radius right curve, right edge | 73.2 m | 173.3% |
250m radius left curve, left edge | 71.3 m | 227.1% |
150m radius right curve, right edge | 56.9 m | 276.3% |
150m radius left curve, left edge | 56.0 m | 208.5% |
HIGH BEAMS | Average minimum useful illumination distance (5 lux) |
---|---|
Straightaway right edge | 123.4 m |
Straightaway left edge | 82.2 m |
250m radius right curve, right edge | 79.4 m |
250m radius left curve, left edge | 78.5 m |
150m radius right curve, right edge | 61.5 m |
150m radius left curve, left edge | 61.8 m |
Front crash prevention: vehicle-to-vehicle
Ratings are given for 2 different trim variations available on this vehicle.
Front crash prevention: pedestrian (day)
Ratings are given for 2 different systems available on this vehicle.
Child seat anchors
Rating applies to 2015-24 models
Overall evaluation | |
Vehicle trim | SEL |
Seat type | leather |
This vehicle has 2 rear seating positions with complete child seat attachment (LATCH) hardware.
It has 1 additional seating position with a tether anchor and the ability to borrow lower anchors from the other seating positions.
Note: When anchors are borrowed, they aren't available to use in their designated positions.
Overall evaluation | |
Vehicle trim | SEL |
Seat type | leather |
G | Good |
A | Acceptable |
M | Marginal |
P | Poor |
Seating positions that rely on borrowed lower anchors or have only a tether anchor available are not rated. | |
thether anchor symbol | Tether anchor |
lower anchor symbol | Lower anchors |
Lower anchor(s) can be borrowed from adjacent positions(s) | |
No hardware available |
Details by seating position
1 | |
---|---|
Tether anchor | |
easy-to-find location | |
other hardware could be confused for anchor | |
Lower anchors | |
too deep in seat | |
not too much force needed to attach | |
easy to maneuver around anchors | |
2 | |
Tether anchor | |
easy-to-find location | |
no other hardware could be confused for anchor | |
Lower anchors | |
Can be borrowed from 1 and 3 | |
3 | |
Tether anchor | |
easy-to-find location | |
other hardware could be confused for anchor | |
Lower anchors | |
not too deep in seat | |
not too much force needed to attach | |
easy to maneuver around anchors |
Seat position 21
Lower anchor A | |
---|---|
Open access rated | No |
Depth (cm) | 0-2 |
Force (lbs) | 29 |
Clearance angle (degrees) | 66 |
Lower anchor B | |
Open access rated | No |
Depth (cm) | 0-2 |
Force (lbs) | 18 |
Clearance angle (degrees) | 70 |
Tether anchor | |
Location | Middle seatback |
Confusing hardware present | Yes |
Has contrasting label within 3 inches of tether anchor |
No |
Tether anchors can be accessed while seatback is properly positioned for use of LATCH |
Not measured |
Seat position 22
Lower anchor A | |
---|---|
Lower latch is shared for this seat position | |
Lower anchor B | |
Lower latch is shared for this seat position | |
Tether anchor | |
Location | Middle seatback |
Confusing hardware present | No |
Has contrasting label within 3 inches of tether anchor |
No |
Tether anchors can be accessed while seatback is properly positioned for use of LATCH |
Not measured |
Seat position 23
Lower anchor A | |
---|---|
Open access rated | No |
Depth (cm) | 2-4 |
Force (lbs) | 22 |
Clearance angle (degrees) | 69 |
Lower anchor B | |
Open access rated | No |
Depth (cm) | 2-4 |
Force (lbs) | 24 |
Clearance angle (degrees) | 68 |
Tether anchor | |
Location | Middle seatback |
Confusing hardware present | Yes |
Has contrasting label within 3 inches of tether anchor |
No |
Tether anchors can be accessed while seatback is properly positioned for use of LATCH |
Not measured |
